Parts Lookup

We're currently in the process of updating and standardizing our parts numbering for all the hooks that we manufacture. If you order spares, you may start to notice these new numbers superseding the legacy numbers on your sales orders or invoices.

If you wish to cross reference legacy to new parts numbers, just use the table below.
You can search by number or description keyword.

Please refer to the Documents page for copies of Maintenance Manuals, which include full diagrams with part numbers.

Note: The number under the model number column indicates how many of each P/N are used in that model.

x01 Remote Hook Spares

P/N	Description	301	601	901	1201	Legacy P/N
72	BOLT ASSEMBLY	---	---	---	---	---
77	BOLT ASSEMBLY	---	---	---	---	---
78	SPRING, KEEPER	---	---	---	---	---
82	BOLT ASSEMBLY	---	---	---	---	---
650	SPRING, LOAD BEAM RETURN	---	1	1	---	86
5178	SPRING	1	---	---	---	129
5874	SPRING	---	---	---	---	---
7411	SEAL	---	1	1	1	15
190340018	SNAP PLUG TERMINAL - MALE	---	2	2	---	71285K93
190340018	SNAP PLUG TERMINAL - MALE	2	2	2	---	71585K93
190380029	SNAP PLUG TERMINAL - FEMALE	---	2	2	2	71285K92
190380029	SNAP PLUG TERMINAL - FEMALE	2	2	2	2	71285K92
---	PIN, LEVER SHAFT	---	---	---	---	7
---	KIT, BOLT ASSEMBLY	---	---	---	---	36
---	KIT, BOLT ASSEMBLY	---	---	---	---	37
---	KIT, BOLT ASSEMBLY	---	---	---	---	38
---	KIT, BOLT ASSEMBLY	---	---	---	---	39
---	KIT, SCREW ASSEMBLY	---	---	---	---	40
---	KIT, BOLT ASSEMBLY	---	---	---	---	41
---	KIT, BOLT ASSEMBLY	---	---	---	---	44
120-010-002-001	SPACER	---	---	---	1	2
120-010-201-005	SIDEPLATE, SOLENOID SIDE	---	---	---	1	1
120-010-202-005	SIDEPLATE, NON-SOLENOID	---	---	---	1	3
120-020-030-001	LOAD BEAM, 1201	---	---	---	1	30
120-040-004-005	SHAFT & ARM ASSY., SS, 1301, 1201	---	---	---	1	4
120-040-010-001	BOSS	---	---	---	---	10
120-040-014-001	BUSHING, SEAL HSG	---	---	---	1	14
120-040-040-050	BUSHING, 1201, SHAFT & ARM	---	---	---	?	04-1
120-040-055-005	ARM, 1201 SHAFT & ARM	---	---	---	?	04-2
120-040-060-005	SHAFT, 1201 SHAFT & ARM	---	---	---	?	04-3
120-050-010-001	SOLENOID COVER, 1201	---	---	---	1	46
120-050-013-001	BEARING CAP, 1201	---	---	---	---	13
120-050-100-001	DATA PLATE, 1201	---	---	---	1	---
120-050-200-001	GUARD, 1201, STANDARD	---	---	---	0	50
120-050-840-001	BUMPER ASSY.	---	---	---	---	84
202-103-4	PIN	1	1	1	1	117
301-010-002-001	SPACER, 301	1	---	---	---	102
301-010-022-005	LATCH SS, 301	1	---	---	---	103
301-010-023-001	ROLLER, LATCH	1	---	---	---	123
301-010-024-001	PIN, ROLLER, LATCH	1	---	---	---	124
301-010-110-005	LINK, SS	1	---	---	---	110
301-010-201-001	SIDE PLATE, SOLENOID SIDE	1	---	---	---	108
301-010-201-002	SIDE PLATE, 301, SOL. SIDE, ORIGINAL CONFIGURATION	0	---	---	---	108
301-010-202-001	SIDE PLATE, NON SOLENOID SIDE	1	---	---	---	106
301-010-202-002	SIDE PLATE, 301, NON SOL. SIDE, ORIGINAL CONFIG.	0	---	---	---	106
301-020-030-001	LOAD BEAM, 301	1	---	---	---	104
301-020-050-005	KEEPER, 301, SS	1	---	---	---	114
301-020-050-005	KEEPER, 301, SS	X	---	---	---	301-020-049-005
301-020-121-001	BUSHING, LOAD BEAM, 301	2	---	---	---	121
301-020-122-001	TRUNNION, LOAD BEAM, 301	1	---	---	---	122
301-040-004-005	SHAFT & ARM ASSY., SS	1	---	---	---	101
301-040-008-005	LEVER, SS, 301	1	---	---	---	100
301-040-014-001	BUSHING, 301	1	---	---	---	125
301-040-098-001	BEARING SPACER	2	---	---	---	98
301-050-010-001	SOLENOID COVER, 301	1	---	---	---	105
301-050-011-001	CASTING, SOLENOID COVER, 301	X	---	---	---	105C
301-050-100-001	DATA PLATE, 301	1	---	---	---	---
301-050-107-001	BUSHING	1	---	---	---	107
301-050-112-005	ARM, LOAD BEAM RETURN	1	---	---	---	112
301-050-126-001	KNOB, MANUAL RELEASE	1	---	---	---	126
301-050-130-005	KEEPER STOP, SS	2	---	---	---	130
301-050-142-001	SPACER, SOLENOID	1	---	---	---	142
301-050-200-002	GUARD, 301, STANDARD	0	---	---	---	115
301-050-210-001	GUARD BUMPER PLATE, 301	X	---	---	---	115-20
301-050-215-001	GUARD, 301 10" BOTTOM RING	X	---	---	---	RING, 10"
301-050-220-001	GUARD, 301 8.75" TOP RING	X	---	---	---	RING 8.75"
301-050-225-001	GUARD SPACER, 301	X	---	---	---	146
301-050-230-001	GUARD, SIDEPLATE, 301	X	---	---	---	115-10
301-050-300-002	301 GUARD, EXTENDED	X	---	---	---	115E
301-050-840-001	BUMPER ASSY., 301	0	---	---	---	113
301-060-097-001	SPRING, LATCH	1	---	---	---	97
301-060-144-005	SPRING, KEEPER	1	---	---	---	144
301-070-141-001	SOLENOID ASSY.	1	---	---	---	141
301-080-099-001	PIN, SPRING RETAINING	2	---	---	---	99
301-080-111-001	PIN, LINK	1	---	---	---	111
301-080-118-001	PIN	2	---	---	---	118
301-080-120-001	PIN, LEVER STOP	1	---	---	---	120
601-010-201-002	SIDE PLATE, SOLENOID SIDE, 601	---	1	---	---	51
601-010-202-002	SIDEPLATE, NON-SOLENOID, 601	---	1	---	---	53
601-040-100-001	WEAR SLEEVE	---	4	---	---	---
601-040-150-001	WEAR SLEEVE	---	2	---	---	---
601-050-100-001	DATA PLATE, 601	---	1	---	---	---
606-020-066-001	BUSHING, LOAD BEAM	---	2	2	---	355
606-020-067-005	TRUNNION, LOAD BEAM	---	---	---	---	352
606-040-056-001	BOSS	---	2	2	---	56
606-040-058-001	BUSHING	---	1	1	---	58
606-050-043-005	BUSHING / KEEPER STOP	---	2	2	2	43
606-050-065-001	BUMPER, LATCH	---	1	1	---	65
606-050-085-005	POST, LOAD BEAM RETURN	1	1	1	---	85
606-050-112-005	ARM, LOAD BEAM RETURN	---	1	1	---	83
606-080-055-001	PIN	---	1	1	---	55
606-080-069-001	PIN, LEVER STOP	---	1	1	---	69
611-010-005-005	LINK, SS	---	1	1	1	5
611-010-017-005	BEARING HOUSING	---	---	---	2	17
611-010-022-005	LATCH, SS, 6111, 1301, 1201	---	---	---	1	22
611-010-023-001	ROLLER, LATCH	---	---	---	1	20
611-010-024-001	PIN, ROLLER	---	---	---	1	21
611-020-028-001	BUSHING, LOAD BEAM	---	---	---	2	28
611-020-029-001	TRUNION, LOAD BEAM	---	---	---	1	152
611-020-049-005	KEEPER, SS	---	---	---	1	49
611-040-008-005	LEVER, SS, 6111,1301,1201,1001, 909, 901, 606, 601	---	1	1	1	8
611-040-010-001	BOSS	---	---	---	2	1010-1
611-040-012-001	BUSHING	---	---	---	1	12
611-040-071-001	BUSHING	---	1	1	1	88
611-050-013-001	BEARING CAP	---	---	---	2	---
611-050-024-001	BUMPER, LATCH	---	---	---	1	24
611-050-033-005	RETAINING RING	---	---	---	1	33
611-050-035-001	SPRING HOUSING	---	---	---	1	35
611-050-058-100	BUMPER ASSY.	---	---	---	1	1058-A1
611-050-080-001	SPACER, SOLENOID	---	1	1	1	80
611-060-025-005	SPRING, LATCH	---	1	1	1	25
611-060-031-001	SPRING	1	1	1	1	31
611-060-034-005	SPRING, LOAD BEAM RETURN	---	---	---	1	34
611-060-078-005	SPRING, KEEPER	---	1	1	1	48/78
611-070-047-001	SOLENOID	---	1	1	1	47
611-080-006-001	PIN, LINK	---	1	1	1	6
611-080-007-001	PIN, LEVER SHAFT	---	---	---	1	1007-1
611-080-011-001	PIN, SPRING RETAINING	---	---	---	2	11
611-080-023-001	TRUNNION, LATCH	---	---	---	1	23
611-080-026-001	PIN	---	1	1	1	26
611-080-027-001	PIN, LEVER SHAFT	---	1	1	1	27
611-080-032-001	PIN, LEVER STOP	---	---	---	1	32
901-010-002-001	SPACER, 601, 901	---	1	1	---	52
901-010-201-005	SIDE PLATE, SS, SOLENOID SIDE	---	---	1	---	350
901-010-202-005	SIDE PLATE, SS, NON SOLENOID SIDE	---	---	1	---	351
901-020-030-001	LOAD BEAM, 601, 901	---	1	1	---	68
901-020-030-100	LOAD BEAM ASSY.	---	x	X	---	---
901-020-049-005	KEEPER, SS, 601 / 901	---	1	1	---	79
901-040-004-005	SHAFT & ARM ASSY., 601 / 901	---	1	1	---	54
901-040-059-001	BUSHING, SEAL HOUSING	---	1	1	---	59
901-050-010-001	SOLENOID COVER, 601 / 901	---	1	1	---	81
901-050-100-001	DATA PLATE, 901	---	---	1	---	---
901-050-200-001	GUARD, 901 / 601, STANDARD	---	X	X	---	87
909-010-020-005	LATCH ASSEMBLY, SS	---	1	1	---	6064-1A
909-010-022-005	LATCH, SS, 601 / 901	---	1	1	---	64
909-010-023-001	ROLLER, LATCH	---	1	---	---	61
909-010-024-001	PIN, ROLLER, LATCH	---	1	1	---	62
909-010-024-001	KIT, ROLLER PIN	---	---	1	---	62
909-050-060-001	KNOB, MANUAL RELEASE	---	---	---	1	16
909-050-060-001	KNOB, MANUAL RELEASE	---	1	1	---	60
909-050-158-001	BUMPER ASSY.	---	1	1	---	6158-A1
909-080-057-001	PIN, SPRING RETAINING	---	2	2	---	57
909-080-069-001	PIN, LEVER STOP	---	---	---	---	---
92373A173	ROLL PIN, 1/8" X 1/4" 18-8	---	---	---	---	---
92373A174	SPRING PIN, 1/8 X 5/16	1	1	1	1	---
92373A215	SLOTTED SPRING PIN	---	---	---	---	---
92383A713	SPRING PIN, 5/32 X 3/4	1	1	1	---	---
92785A433	SET SCREW	1	---	---	---	---
92785A435	SET SCREW, 1/4-20 X 3/8	1	1	1	1	1/4-20 X 3/8
960-SJW-143-003	14/3 CABLE, 2 FT LG.	1	1	1	---	14_3 CABLE
AN3-14A	SCREW	---	4	4	4	---
AN3-15A	BOLT	1	---	---	---	---
AN320-12	NUT, CASTELLATED	---	2	2	---	---
AN4-17A	BOLT	---	---	X	---	---
AN4-20A	BOLT	---	2	2	---	---
AN4-21A	BOLT	1	---	---	2	---
AN4-24A	BOLT	1	---	---	---	---
AN4-5A	BOLT	1	1	1	---	---
AN502-1032-8	SCREW	---	---	---	---	45
AN6-25A	BOLT	---	---	1	---	---
AN6-27A	BOLT	---	1	1	---	---
AN6-31A	BOLT	---	---	---	1	---
AN8-25A	BOLT	---	1	---	---	---
AN960-616L	WASHER	---	---	---	---	116
B-610	BEARING	1	---	---	---	127
BH-1012	BEARING	---	---	1	---	70
MIL-G-81322	GREASE	A/R	A/R	A/R	A/R	---
MR12N	BEARING	---	---	---	2	18
MS20995C025	SAFETY WIRE, Ø.025	A/R	A/R	A/R	A/R	---
MS21044N3	NUT, SELF LOCKING	2	---	---	---	---
MS21044N4	NUT, SELF LOCKING	3	3	3	3	AN365-428
MS21044N6	NUT, SELF LOCKING	1	2	2	2	AN365-624
MS21083N10	NUT, SELF LOCKING	---	1	1	---	---
MS21083N3	NUT	2	---	---	---	---
MS21083N4	NUT, SELF LOCKING	---	2	2	2	---
MS21318-14	DRIVE SCREW	4	4	4	4	---
MS24461-4	BEARING	1	---	---	---	109
MS24461-6	BEARING	---	1	1	1	9
MS24465-4	BEARING	1	---	---	---	119
MS24465-6	BEARING	---	1	1	1	29
MS24665-372	COTTER PIN	---	2	2	---	---
MS24673-1	SCREW	4	---	---	---	---
MS24694-S114	SCREW, CSK	1	---	---	---	---
MS24694S118	SCREW	---	1	1	---	---
MS24694S122	SCREW	---	---	---	1	---
MS24694S50	SCREW	2	---	---	---	---
MS24694-S67	SCREW	X	---	---	---	---
MS24694S69	SCREW	1	---	---	---	MS24694S69
MS24694S97	SCREW	---	---	---	2	42
MS24694S97	SCREW	---	2	2	---	73
MS35265-44	SCREW	---	---	---	---	140
MS35489-69	GROMMET	1	1	1	1	---
NAS1149F0332P	WASHER	2	---	---	---	---
NAS1149F0363P	WASHER	2	---	---	4	NAS1149F0363P
NAS1149F0432P	WASHER	3	3	4	2	AN960-416L
NAS1149F0463P	WASHER	4	---	---	1	AN960-416
NAS1149F0632P	WASHER	3	4	4	2	AN960-616L
NAS1149F0663P	WASHER	---	---	---	2	---
NAS1149F1032P	WASHER	---	3	3	---	AN960-1016L
NAS1149F1232P	WASHER	---	4	4	---	AN960-1216L
NAS1306-20	BOLT	1	---	---	---	---
NAS6210-24	BOLT	---	1	1	---	---
RR-125	RETAINING RING	---	---	---	2	19

Primary Hook Spares

P/N	Description	202-2/5	606	909	6111	Legacy P/N
202-103-4	ROLLER PIN	1	1	1	1	3117-1
1/4-20 X 3/8"	SET SCREW	---	1	1	1	---
611-010-005-005	LINK, SS	---	1	1	1	6005-1/5
611-040-008-005	LEVER, SS	---	1	1	1	6008-1/8
611-040-148-001	RELEASE ARM, LOWER	---	1	1	1	6148-1
611-060-025-005	SPRING, LATCH	---	1	1	1	6025-1
611-060-031-001	SPRING	---	1	1	1	3031-1
611-070-047-001	SOLENOID	---	1	1	1	6047-1/47
611-080-006-001	PIN, LINK	---	1	1	1	6006-1
611-080-027-001	PIN, LEVER SHAFT	---	1	1	1	6027-1
92373A174	ROLL PIN, .125 x .3125 SS	---	1	1	1	---
MS24461-6	BEARING	---	1	1	1	6NBC914YZP/9
MS24465-6	BEARING	---	1	1	1	6NBF817YJ/29
92373A217	SPRING PIN, 5/32 X 1	---	2	1	1	---
611-040-071-005	BUSHING	---	---	1	1	1071-1
MS35265-43	SCREW	---	---	1	1	---
611-080-026-001	PIN	---	1	1	2	6026-1
606-080-055-001	PIN	---	1	1	---	6055-1
909-010-022-005	LATCH	---	1	1	---	6064-1
909-010-025-001	BUSHING, LATCH	---	1	1	---	6070-1
909-050-060-001	KNOB, MANUAL RELEASE	---	1	1	---	6060-1/1519426
909-050-158-001	BUMPER ASSY.	---	1	1	---	6158-A1
MS21083N10	NUT, SELF LOCKING	---	1	1	---	---
1140	CORD GRIP	---	---	1	---	---
500388-0001	LOAD CELL TRUNNION	---	---	1	---	500388-001
503052-0002	LOAD INDICATOR	---	---	1	---	---
9022-1	WIRE HARNESS	---	---	1	---	9022
9051-1	SIDE PLATE, SOLENOID SIDE	---	---	1	---	---
9052-1	SPACER, BLACKHAWK	---	---	1	---	---
9053-1	SIDE PLATE, NON SOLENOID SIDE	---	---	1	---	---
9054-101	SHAFT AND ARM ASSY, NON HYD	---	---	1	---	---
9064-1	LATCH STOP	---	---	1	---	---
9067-1	TRUNNION	---	---	1	---	---
9080-1	CABLE MOUNT	---	---	1	---	---
9081-1	SOLENOID COVER	---	---	1	---	---
9085-1	COVER PLATE	---	---	1	---	---
9087-3	PLACARD	---	---	1	---	---
9090-1	TRUNNION, FORE	---	---	1	---	---
909-010-023-001	ROLLER, LATCH	---	---	1	---	---
909-010-024-001	PIN, ROLLER, LATCH	---	---	1	---	---
909-050-065-001	LATCH BUMPER	---	---	1	---	---
9104-2	LOAD BEAM	---	---	1	---	9104-1
9127-1	ABRASION PLATE	---	---	1	---	---
9127-3	ABRASION PLATE	---	---	1	---	---
MS21919WDG6	CLAMP	---	---	1	---	---
MS35207-261	SCREW	---	---	1	---	---
MS35207-262	SCREW	---	---	1	---	---
NAS6210-32	BOLT	---	---	1	---	---
NAS1149F1232P	WASHER	---	5	2	1	AN960-1216L
611-080-032-001	PIN, LEVER STOP	---	---	2	1	1032-1
MS21044N6	NUT	---	1	2	7	AN310-6
909-080-057-001	PIN, SPRING RETAINING	---	2	2	---	6057-1
AN320-12	NUT, CASTELLATED	---	2	2	---	---
MS24665-372	COTTER PIN	---	2	2	---	---
MS21044N6	NUT	---	4	2	---	AN365-624
NAS1149F0632P	WASHER	---	7	2	---	AN960-616L
320555	KNIFE DISCONNECT	---	---	2	---	---
9056-1	BOSS	---	---	2	---	---
9058-1	BUSHING	---	---	2	---	---
9066-1	BUSHING, LOAD BEAM TRUNNION	---	---	2	---	---
AN3-23A	BOLT	---	---	2	---	---
AN4-23A	BOLT	---	---	2	---	---
AN6-24A	BOLT	---	---	2	---	---
AN8-25A	BOLT	---	---	2	---	---
MS21044N3	NUT	---	---	2	---	---
MS21044N8	NUT	---	---	2	---	---
MS35266-68	SCREW	---	---	2	---	---
NAS1149F0832P	WASHER	---	---	2	---	---
NAS1149F1032P	WASHER	---	3	3	---	AN960-1016L
NAS1149F0432P	WASHER, FLAT	7	6	4	2	AN960-416L
AN502-10-8	SCREW	---	4	4	---	---
MS21044N4	NUT	---	6	4	---	AN365-428
NAS1149F0332P	WASHER, FLAT	3	---	4	---	AN960-10L
AN7-24A	BOLT	---	---	4	---	---
MS21044N7	NUT	---	---	4	---	---
MS21318-14	DRIVE SCREW	---	---	4	---	---
MS24693S297	SCREW, FLAT HEAD	---	---	4	---	---
MS35266-63	SCREW	---	---	4	---	---
NAS1149F0732P	WASHER	---	---	4	---	---
MS27039C1-07	SCREW	---	---	8	---	---
MIL-G-81322	GREASE	A/R	A/R	A/R	A/R	---
MS20995C025	SAFETY WIRE, Ø.025	A/R	A/R	A/R	A/R	---
6064-4	LATCH BUSHING	---	---	NIQ	---	---
9104-100	LOAD BEAM ASSEMBLY	---	---	NIQ	---	---
606-080-069-001	PIN, LEVER STOP	---	1	X	---	6069-1/69
6064-2	ROLLER, LATCH	---	1	X	---	---
6064-3	PIN, ROLLER, LATCH	---	1	X	---	---
611-080-047-001	SOLENOID PIN	---	1	X	---	6113-1
MS21318-1	SCREW, DRIVE	4	---	X	---	---
120-040-004-005	SHAFT & ARM ASSY., SS, 1301, 1201	---	---	X	---	4
9089-1	CABLE ASSY	---	---	X	---	---
909-010-020-005	LATCH ASSEMBLY, SS	---	---	X	---	6064-A1
92373A173	ROLL PIN, 1/8" X 1/4" 18-8	---	---	X	---	---
MS20365-1032L	NUT	---	---	X	---	---
MS20365-428L	NUT	---	---	X	---	---
MS20365-624L	NUT	---	---	X	---	---
MS20365-720L	NUT	---	---	X	---	---
MS20365-816L	NUT	---	---	X	---	---
MS27039C1	SCREW, PHILLISTER HEAD	---	---	X	---	---
MS35266-69	SCREW	---	---	X	---	---
NAS1149FN316P	WASHER	---	---	X	---	---
AN4-21A	BOLT	---	---	---	2	---
606-050-085-005	POST, LOAD BEAM RETURN	---	1	---	---	3085-1
AN3-15A	BOLT	1	---	---	---	---
3154-1	FITTING	---	---	---	---	---
611-050-080-001	SPACER, SOLENOID	---	1	---	1	6080-1
611-060-078-005	SPRING, KEEPER	---	1	---	1	6078-1
AN6-27A	BOLT	---	2	---	1	---
7411	SEAL	---	---	---	1	CR7411
611-010-002-001	SPACER, 6111	---	---	---	1	1002-1
611-010-017-005	BEARING HOUSING	---	---	---	1	1017-1
611-010-022-005	LATCH, SS, 6111, 1301, 1201	---	---	---	1	1022-1/22
611-010-023-001	ROLLER, LATCH	---	---	---	1	1022-2
611-010-024-001	PIN, ROLLER	---	---	---	1	1022-3
611-010-201-001	SIDE PLATE, 6111, SOLENOID SIDE	---	---	---	1	1001-1
611-010-202-001	SIDE PLATE, 6111, NON SOLENOID SIDE	---	---	---	1	1003-1
611-020-029-001	TRUNION, LOAD BEAM	---	---	---	1	1029-1
611-020-030-001	LOAD BEAM, 6111	---	---	---	1	1030-1
611-020-049-005	KEEPER, SS	---	---	---	1	1049-A1
611-040-004-005	SHAFT & ARM ASSY., SS, 6111	---	---	---	1	1004-A1
611-040-012-001	BUSHING	---	---	---	1	1012-1
611-040-090-001	COVER	---	---	---	1	1090-1
611-040-091-001	SPACER BLOCK	---	---	---	1	1091-1
611-040-154-001	NIPPLE FITTING (MODIFIED)	---	---	---	1	3415-1
611-050-010-001	SOLENOID COVER	---	---	---	1	1046-1
611-050-016-001	KNOB, MANUAL RELEASE	---	---	---	1	1016-1
611-050-024-001	BUMPER, LATCH	---	---	---	1	1024-1
611-050-058-100	BUMPER ASSY.	---	---	---	1	1058-A1
611-060-034-005	SPRING, LOAD BEAM RETURN	---	---	---	1	1034-1/34
611-080-007-001	PIN, LEVER SHAFT	---	---	---	1	1007-1
611-080-023-001	TRUNNION, LATCH	---	---	---	1	1023-1
AN6-31A	BOLT	---	---	---	1	---
MS3102E14S-6P	CONNECTOR	---	---	---	1	---
MS21083N4	NUT	3	---	---	2	---
611-020-028-001	BUSHING, LOAD BEAM	---	---	---	2	1028-1
611-040-010-001	BOSS	---	---	---	2	1010-1
611-040-043-005	KEEPER STOP	---	---	---	2	1043-1
611-050-013-001	BEARING CAP	---	---	---	2	1013-1
611-050-033-005	RETAINING RING	---	---	---	2	1033-1
611-050-035-001	SPRING HOUSING	---	---	---	2	1035-1
611-080-011-001	PIN, SPRING RETAINING	---	---	---	2	1011-1
MR12N	BEARING	---	---	---	2	18
RR-125	RETAINING RING	---	---	---	2	19
MS24694S97	SCREW	---	2	---	4	AN509-416R9
MS35265-30	SCREW	---	4	---	4	---
AN3-14A	BOLT, HEX HEAD	2	---	---	4	---
MS24693S276	SCREW	---	---	---	4	---
NAS1149F0363P	WASHER	---	---	---	4
AN6-22A	BOLT	---	1	---	5	AN6-22A
NAS1149F0663P	WASHER	---	---	---	9	AN960-616
3129-1	SPRING	---	1	---	---	5874
6051-1	SIDE PLATE, SOLENOID SIDE	---	1	---	---	---
6053-1	SIDE PLATE, NON SOLENOID SIDE	---	1	---	---	---
6054-A1	SHAFT AND ARM ASSY	---	1	---	---	---
606-010-002-001	SPACER	---	1	---	---	6052-1
606-020-030-001	LOAD BEAM	---	1	---	---	6068-1
606-020-067-005	TRUNNION, LOAD BEAM	---	1	---	---	6067-1
606-050-010-001	SOLENOID COVER	---	1	---	---	6081-1
606-050-065-001	BUMPER, LATCH	---	1	---	---	6065-1
606-050-092-001	BUMPER RING	---	1	---	---	---
606-050-112-005	ARM, LOAD BEAM RETURN	---	1	---	---	6083-1
6079-1	KEEPER	---	1	---	---	6079-A1
6083-A1	ARM	---	1	---	---	---
611-040-071-001	BUSHING	---	1	---	---	88
AN380-3-3	COTTER PIN	---	1	---	---	---
AN6-20A	BOLT	---	1	---	---	---
AN6-25A	BOLT	---	1	---	---	---
AN6-27	BOLT	---	1	---	---	---
MS3102R16S-5P	ELECTRICAL CONNECTOR	---	1	---	---	---
MS35265-42	SCREW	---	1	---	---	---
NAS6210-24	BOLT	---	1	---	---	---
NIQ	PIN	---	1	---	---	6061-1
NIQ	ROLL PIN	---	1	---	---	191-51
NIQ	ROLL PIN	---	1	---	---	241-51
NIQ	ROLL PIN	---	1	---	---	247-51
NIQ	SCREW	---	1	---	---	AN509-416R29
NIQ	SCREW	---	1	---	---	AN520-10-8
NIQ	COTTER PIN	---	1	---	---	MS24665-253
NIQ	BOLT	---	1	---	---	NAS1110-24
606-010-095-001	BUSHING	---	2	---	---	---
606-020-066-001	BUSHING, LOAD BEAM	---	2	---	---	6066-1/66
606-040-056-001	BOSS	---	2	---	---	6056-1
606-040-058-001	BUSHING	---	2	---	---	6058-1
6090-1	BUSHING	---	2	---	---	---
6091-1	BUSHING	---	2	---	---	---
AN4-17A	BOLT	---	2	---	---	---
MS24694S118	SCREW	---	2	---	---	---
NAS1149F0616P	WASHER	---	2	---	---	---
NAS1149F0463P	WASHER	---	3	---	---	AN960-416
AN4-14A	BOLT, HEX HEAD	3	4	---	---	---
606-050-043-005	BUSHING / KEEPER STOP	---	4	---	---	6043-1
OBSOLETE	BUMPER RING	---	X	---	---	6092-1
OBSOLETE	BUMPER	---	X	---	---	6094-1
5960	SPRING, EXTENSION	1	---	---	---	---
202-102-1	SPACER	1	---	---	---	---
202-103-1	LATCH	1	---	---	---	---
202-103-100	LATCH ASSEMBLY	1	---	---	---	---
202-103-2	LATCH BUSHING	1	---	---	---	---
202-103-3	LATCH ROLLER	1	---	---	---	---
202-104-1	LOAD BEAM	1	---	---	---	---
202-105-1	SOLENOID COVER	1	---	---	---	---
202-105-5	DATA PLATE	1	---	---	---	202-105-3
202-106-1	SIDE PLATE, NON SOLENOID SIDE	1	---	---	---	202-106-2
202-108-1	SIDE PLATE, SOLENOID SIDE	1	---	---	---	202-108-2
202-110-1	LINK	1	---	---	---	---
202-111-1	SHAFT AND ARM	1	---	---	---	---
202-111-131-001	202, SHAFT & ARM / LEVER ASSY.	1	---	---	---	---
202-113-1	BUMPER	1	---	---	---	---
202-120-1	PIN	1	---	---	---	---
202-127-3	ABRASION PLATE	1	---	---	---	202-127-1
202-127-4	ABRASION PLATE	1	---	---	---	202-127-2
202-128-1	RELEASE COVER	1	---	---	---	---
202-129-1	RELEASE ARM	1	---	---	---	---
202-130-1	BLOCK, SPACER	1	---	---	---	---
202-131-1	LEVER	1	---	---	---	202-100-1
202-131-2	BUSHING	1	---	---	---	---
202-141-100	SOLENOID ASSEMBLY	1	---	---	---	---
202-141-2	PIN	1	---	---	---	---
202-143-1	PIN	1	---	---	---	---
202-155-2	STOP BLOCK	1	---	---	---	---
202-198-1	PIN	1	---	---	---	---
92373A106	ROLL PIN, 1/16 X 5/16 18-8 SS	1	---	---	---	---
92373A179	ROLL PIN, 1/8 X 5/8 18-8	1	---	---	---	---
92373A181	ROLL PIN, 1/8 X 3/4 18-8 SS	1	---	---	---	---
92373A182	ROLL PIN, 1/8 X 7/8 18-8 SS	1	---	---	---	---
M-29	SPRING, EXTENSION	1	---	---	---	---
MS35265-27	SCREW	1	---	---	---	---
PC07A8-2P	CONNECTOR	1	---	---	---	---
202-107-1	SHAFT & ARM BUSHING	2	---	---	---	---
202-118-1	PIN	2	---	---	---	---
202-122-1	LOAD BEAM BUSHING	2	---	---	---	---
202-135-1	SPACER	2	---	---	---	---
202-136-2	TOP ATTACHMENT BUSHING	2	---	---	---	---
202-199-1	PIN	2	---	---	---	---
AN365-632A	NUT, SELF LOCKING	2	---	---	---	---
SRW188ZZA5	BEARING	2	---	---	---	SRW18877A5
MS21083N3	NUT, SELF LOCKING	3	---	---	---	---
MS35265-35	SCREW	3	---	---	---	---
MS35265-34	SCREW, PHILLISTER HEAD	6	---	---	---	---
MS35265-14	SCREW	8	---	---	---	---
202-100-2	BUSHING	?	---	---	---	---
202-100-4	ROLLER PIN	?	---	---	---	---
202-100-100	LEVER ASSEMBLY	X	---	---	---	---
202-104-100	LOAD BEAM ASSEMBLY	X	---	---	---	---
202-104-2	TRUNNION	X	---	---	---	---
202-141-1	SOLENOID COVER	X	---	---	---	---
98296A021	PIN, SPRING	X	---	---	---	---
98296A879	PIN, SPRING	X	---	---	---	---
98296A881	PIN, SPRING	X	---	---	---	---
98296A883	PIN, SPRING	X	---	---	---	---
MS35265-13	SCREW, PHILLISTER HEAD	X	---	---	---	---
MS35265-36	SCREW, PHILLISTER HEAD	X	---	---	---	---
1000-1	DATA TAG	---	---	---	---	---
611-040-152-100	ASSY, SHAFT & ARM AND LEVER	---	---	---	---	1152-A1
6NBC914YZP	BEARING	---	---	---	---	---
92785A435	SET SCREW, 1/4-20 X 3/8	---	---	---	---	---
AN4-22A	BOLT	---	---	---	---	---
AN6-30A	BOLT	---	---	---	---	---

Remote Hook Guard Componants

REF	Part Number	Description	301	601	901	1201
A	1/2-13 X 2-1/2 GR8 BOLT	BOLT	1
A	301-050-225-001	GUARD SPACER, 301	1
A	1/2"-13 NYLOC	NUT	1
A	NAS1149F0832P	WASHER	2
A	3/4-10 X 3-1/4 GR 8 BOLT	BOLT, MODEL 601/901 GUARD		1	1
A	901-050-225-005	GUARD SPACER, 601/901 SS		1	1
A	3/4-10 NYLOC NUT	NYLON INSERT LOCK NUT		1	1	1
A	00385-3200-2	3/4" (1 7/16" OD) F436 HARD WASHER ZY IMPORT		2	2	2
A	3/4-10 X 3-3/4 GR8 BOLT	BOLT, 1201 GUARD				1
A	120-050-225-005	GUARD SPACER, 1201				1
B	MS21044N6	NUT	2
B	NAS1149F0632P	WASHER	2
B	AN6-22A	BOLT	2
B	NAS1149F0832P	WASHER		2	2	2
B	MS21044N8	NUT		2	2	2
B	AN8-26A	BOLT		2	2
B	AN8-31A	BOLT				2
C	NAS1149F0332P	WASHER	2	2	2	2
C	AN3-6A	BOLT	1	1	1	1
C	MS21919WDG6	CLAMP	1	1	1	1
C	MS21044N3	NUT	1	1	1	1
D	301-050-840-001	BUMPER ASSY., 301 (INC 5/16-18 NYLOC NUT)	1
D	120-050-840-001	BUMPER ASSY. (INC 3/8-16 NYLOC NUT)		1	1	1
E	AN4-21A	BOLT	1
E	AN6-25A	BOLT		1	1
E	AN6-31A	BOLT				1
E	NAS1149F0463P	WASHER	1
E	NAS1149F0632P	WASHER		1	1	1
E	MS21044N4	NUT	1
E	MS21044N6	NUT		1	1	1
